CAT6 U/UTP Data Cable | 400 MHz | LSZH-Dca | 500m | Grey
Features
Category 6 U/UTP solid cable with standardized twisted pairs which is used for ethernet applications that require up to 400 MHz performance specifications.
Properties
- Basic Conductor: Bare copper wire 23 AWG
- Insulation: Polyolefin
- Cable Diameter: 6.0 mm
- Number of Insulated Conductors: 8 / 4 twisted pairs
- Color Codes of Pairs: Blue x White/Blue | Orange x White/Orange | Green x White/Green | Brown x White/Brown
- Outer Sheath: LSZH (Halogen free) flame retardant
- Standard Outer Sheath Color: Grey RAL 7001
- Bending radius (Moving): 8xCable outer diameter (mm)
- Bending radius (Fixed): 4xCable outer diameter (mm)
- Operating Temperature: -20 to +60C
- Installation Temperature: 0 to +50C
Standards
- ANSI / TIA / 568.2-D
- IEC 61156-5 (ISO / IEC-11801 2.)
- EN 50173-1, EN 50288-6-1
Applications
- IEEE 802.3: 10Base-T; 100Base-T; 1000Base-T
- IEEE 802.5 16 MB; ISDN; TPDDI; ATM
- Power over Ethernet (PoE) / PoE+
EU Declaration
- Low Voltage Directive (LVD) 2014/35/EU
- Restriction of Hazardous Substances Directive (RoHS) 2011/65/EU
Flame Resistance
- Euroclass: Dca – s2, d2, a1
- Flame Performance: Flame Retardancy EN 60332-1-2, Smoke Performance EN 61034-2, Halogen Acidity EN 60754-1/2
| Packing Size (cm) | Packing Weight (Kg) |
|---|---|
| 27 x 39 x 39 | 20 |
